German Type Zebra Hose Clamp

#NCLMX13

Product Description

German Type Zebra Hose Clamp

German Type Hose Clamp consist of a band, often galvanized or stainless steel, into which a screw thread pattern has been cut or pressed.One end of the band contains a captive screw. The clamp is put around the hose or tube to be connected, with the loose end being fed into a narrow space between the band and the captive screw. When the screw is turned, it acts as a worm drive pulling the threads of the band, causing the band to tighten around the hose (or when screwed the opposite direction, to loosen). Screw clamps are normally used for hoses 1/2 inch diameter and up, with other clamps used for smaller hoses.

TIGHTENING TORQUE:

German type hose clamp recommended installation free torque is less than 1Nm,load torque is 6.5Nm.

MAIN APPLICATIONS:

German type hose clamp is widely used in automobiles, tractors, forklifts, locomotives, ships, mines petroleum,chemicals,pharmaceuticals,agricultures and other water,oil,steam,dust etc

You can see some usage scenario in below picture.

MAIN FEATURES:
